Themes and applications for CSE 20

Applications: Numbers (how to represent them and use them in Computer Science), Recommendation systems and their roots in machine learning (with applications like Netflix), “Under the hood" of computers (circuits, pixel color representation, data structures), Codes and information (secret message sharing and error correction), Bioinformatics algorithms and genomics (DNA and RNA).

Introductions

(I am transitioning from Canvas to a new resource that the department has been developing. It has been initiated by Mia Minnes and Joe Politz with help from Aiko Coanaya and Akanksha Pandey.)

Pro-tip: you can use MATH109 to replace CSE20 for prerequisites and other requirements.

On a typical week: TuTh Lectures + review quizzes, W HW due, M Discussion, office hours, Piazza. Tests and Midterms see the content calendar.

Tuesday March 29

What data should we encode about each Netflix account holder to help us make effective recommendations?

In machine learning, clustering can be used to group similar data for prediction and recommendation. For example, each Netflix user’s viewing history can be represented as a \(n\)-tuple indicating their preferences about movies in the database, where \(n\) is the number of movies in the database. People with similar tastes in movies can then be clustered to provide recommendations of movies for one another. Mathematically, clustering is based on a notion of distance between pairs of \(n\)-tuples.

In the table below, each row represents a user’s ratings of movies: (check) indicates the person liked the movie, (x) that they didn’t, and \(\bullet\) (dot) that they didn’t rate it one way or another (neutral rating or didn’t watch). Can encode these ratings numerically with \(1\) for (check), \(-1\) for (x), and \(0\) for \(\bullet\) (dot).

Person	Fyre	Frozen II
\(P_1\)		\(\bullet\)
\(P_2\)
\(P_3\)
\(P_4\)	\(\bullet\)

Conclusion: Modeling involves choosing data types to represent and organize data

Discrete Math vs Continuous Math

2 Continuous Math
image reference
Continuous math is the study of the real number line
What are some subjects that would be considered as continuous math?

Discrete Math
image reference
Discrete math deals with distinct objects (like the integers.)
What are some subjects that would be considered as discrete math?

Notation and prerequisites

Term	Notation Example(s)	We say in English …
sequence	\(x_1, \ldots, x_n\)	A sequence \(x_1\) to \(x_n\)
summation	\(\sum_{i=1}^n x_i\) or \(\displaystyle{\sum_{i=1}^n x_i}\)	The sum of the terms of the sequence \(x_1\) to \(x_n\)

all reals	\(\mathbb{R}\)	The (set of all) real numbers (numbers on the number line)
all integers	\(\mathbb{Z}\)	The (set of all) integers (whole numbers including negatives, zero, and positives)
all positive integers	\(\mathbb{Z}^+\)	The (set of all) strictly positive integers
all natural numbers	\(\mathbb{N}\) or \(\mathbb{Z}^{\geq 0}\)	The (set of all) natural numbers. Note: we use the convention that \(0\) is a natural number.

piecewise rule definition	\(f(x) = \begin{cases} x & \text{if~}x \geq 0 \\ -x & \text{if~}x<0\end{cases}\)	Define \(f\) of \(x\) to be \(x\) when \(x\) is nonnegative and to be \(-x\) when \(x\) is negative
function application	\(f(7)\)	\(f\) of \(7\) or \(f\) applied to \(7\) or the image of \(7\) under \(f\)
	\(f(z)\)	\(f\) of \(z\) or \(f\) applied to \(z\) or the image of \(z\) under \(f\)
	\(f(g(z))\)	\(f\) of \(g\) of \(z\) or \(f\) applied to the result of \(g\) applied to \(z\)

absolute value	\(\lvert -3 \rvert\)	The absolute value of \(-3\)
square root	\(\sqrt{9}\)	The non-negative square root of \(9\)

Computers encode mathematical objects into data types. What are some examples of data types?

Data Types: sets, \(n\)-tuples, and strings

Term	Examples:
	(add additional examples from class)
set unordered collection of elements	\(7 \in \{43, 7, 9 \}\) \(2 \notin \{43, 7, 9 \}\)
repetition doesn’t matter
Equal sets agree on membership of all elements
\(n\)-tuple (also called an \(n\)-dimensional vector) ordered sequence of entries with \(n\) “slots" (\(n >0\))
repetition matters, fixed length
Equal \(n\)-tuples have corresponding entries equal
string ordered finite sequence of elements each from specified set
repetition matters, arbitrary finite length
Equal strings have same length and corresponding characters equal

A string of length \(0\) is called the empty string and is denoted \(\lambda\).

A set with no elements is called the empty set and is denoted \(\{\}\) or \(\emptyset\).

Sets

Recall that the empty set (denoted \(\emptyset\) or \(\{~\}\)) is the set without any elements.

To define a set using roster method, explicitly list its elements using curly braces. That is, start with \(\{\) then list elements of the set separated by commas and close with \(\}\).

To define a set using set builder definition, either form “The set of all \(x\) from the universe \(U\) such that \(x\) is ..." by writing \[\{x \in U \mid ...x... \}\] or form “the collection of all outputs of some operation when the input ranges over the universe \(U\)" by writing \[\{ ...x... \mid x\in U \}\]

We use the symbol \(\in\) as “is an element of” to indicate membership in a set.

Example sets: For each of the following, identify whether it’s defined using the roster method or set builder notation and give an example element.

\(n\)-tuples

To define \(n\)-tuples, list the entries separated by commas and enclosed by parentheses.

Example \(n\)-tuples: For each of the following \(n\)-tuple, come up with where it might come from. For example, \((88, 79, 100, 90, 68, 81,90)\) may be the grades a particular student will get for homeworks 1-7.

strings (over a finite alphabet)

A string over a finite alphabet is a finite sequence of characters or symbols.

Recall that the empty string, (usually denoted \(\lambda\)) is the string without any characters.

The characters you are allowed to use come from a finite set called an alphabet.

Usually, a string is given as a list of characters without any punctuation. In some cases, we will use the symbol “\(\circ\)" as a delimiter. For example, if the alphabet is \(\{\texttt{A},\texttt{C},\texttt{U},\texttt{G}\}\), then consider the string \(\texttt{A}\texttt{A}\texttt{A}\texttt{U}\texttt{A}\). It could also be written as \(\texttt{A}\circ\texttt{A}\circ\texttt{A}\circ\texttt{U}\circ\texttt{A}\).

String concatenation of strings \(x\) and \(y\), denoted \(xy\) or \(x\circ y\) is the result of “gluing together" the strings \(x\) first then \(y\). For example: \(\texttt{A}\texttt{U}\texttt{A}\texttt{A}\circ \texttt{G}\texttt{G}\texttt{C}=\texttt{A}\texttt{U}\texttt{A}\texttt{A}\texttt{G}\texttt{G}\texttt{C}\).

Pro-tip: the meaning of writing one element next to another like \(xy\) depends on the data-types of \(x\) and \(y\). When \(x\) and \(y\) are strings, the convention is that \(xy\) is the result of string concatenation. When \(x\) and \(y\) are numbers, the convention is that \(xy\) is the result of multiplication. This is (one of the many reasons) why is it very important to declare the data-type of variables before we use them.
